Schneider Electric
PowerLogic PM5560 — METSEPM5560
A panel-mounted meter for energy monitoring and power-quality analysis in commercial and industrial installations.
Technical specifications
| Parameter | Value |
|---|---|
| Active energy accuracy | Class 0.2S |
| Ethernet ports | 2 |
| Serial interface | RS485 |
| Digital inputs / outputs | 4 DI / 2 DO |
| Harmonic analysis | Up to 63rd harmonic |
| Panel dimensions | 96 × 96 mm |
Applications and use cases
- Electrical consumption and power-quality monitoring in commercial or industrial buildings.
- Independent measurement at a PV, storage or charging installation connection point.
Equipment scope / supply scope
- This entry is the METSEPM5560 meter; confirm the exact device reference in the quotation.
- Select external current transformers, voltage measurement arrangements and protective devices for the installation; do not assume they are included with the meter.
- Specify the required communications and supervisory software integration separately.
Installation considerations
- Provide a correctly sized panel opening, suitable enclosure and access for wiring.
- An electrician must select the wiring scheme, CT ratios/polarity, auxiliary supply and protection from the PM5500/5600/5700 manual.
- Commission voltage/current settings, communications addresses and alarm thresholds before using the readings for operational decisions.
