FoxESS
G-MAX Plus GM241kWh-125kW-H
An all-in-one commercial storage system with a hybrid PCS and integrated battery management.
G-MAX Plus series photograph; configuration is confirmed for the project.
Technical specifications
| Parameter | Value |
|---|---|
| Nominal AC output power | 125 kW |
| Battery system capacity | 241 kWh |
| Battery chemistry | LFP |
| Maximum PV input power | 250 kW |
| MPPT trackers | 8 |
| Cabinet protection | IP55 |
| Dimensions W × H × D | 1040 × 2230 × 1500 mm |
| Nominal AC voltage | 380 / 400 V |
Applications and use cases
- Commercial solar self-consumption and scheduled storage.
- A candidate for sites requiring a hybrid storage cabinet.
Equipment scope / supply scope
- Integrated battery, BMS, hybrid PCS and liquid cooling architecture.
- The quotation defines delivery accessories and commissioning.
Configuration
- PV arrays, generator equipment, metering and site switchgear are project-specific.
- Backup operation requires the appropriate electrical design and selected equipment.
Installation considerations
- Plan cabinet access, load-bearing foundation, cable routes and service space.
- Confirm grid connection, protection settings and commissioning before operation.
